Slime heavy medium cyclone
EP≤0.08, separation efficiency ≥90%; The lower limit of effective sorting size can reach 0.1-0.074mm, and the Ep value is much lower than the traditional spiral sorting machine or TBS sorting machine, eliminating the need for coal slime heavy media recovery system. Generally, the qualified medium of coarse refined coal is used for heavy medium separation of coal slime.
Product introduction
The heavy medium cyclone makes full use of the medium properties of the medium system to separate coarse coal slime again.
EP≤0.08, separation efficiency ≥90%; The lower limit of effective sorting size can reach 0.1-0.074mm, and the Ep value is much lower than the traditional spiral sorting machine or TBS sorting machine, eliminating the need for coal slime heavy media recovery system. Generally, the qualified medium of coarse refined coal is used for heavy medium separation of coal slime.
Technical characteristics
An adjustable overflow device is designed, and the separation density can be adjusted online by adjusting the insertion depth of the overflow tube of the cyclone. The internal wear-resistant layer is customized with 98% Al2O3 high aluminum ceramic according to the flow path design of the cyclone, which fully fits the flow path change, and has the characteristics of good wear resistance, long service life, light weight of wearing parts and high performance-to-price ratio.
Scope of application
Will not be bad, mainly used in coal slime heavy medium separation process.
Specification and size | Barrel diameter（mm） | Pressure requirementMPa | Upper bound kernel（mm） | Handling capacity（t/h） | throughput （m3/h） |
SmaxMZ150 | 150 | 0.12-0.18 | 0.5 | 4-10 | 20-35 |
SmaxMZ 200 | 200 | 0.18-0.22 | 0.5 | 10-15 | 35-55 |
SmaxMZ 250 | 250 | 0.22-0.24 | 1.0 | 15-20 | 55-80 |
SmaxMZ 300 | 300 | 0.24-0.28 | 1.0 | 20-30 | 80-120 |
SmaxMZ 350 | 350 | 0.26-0.30 | 1.0 | 30-40 | 120-160 |
SmaxMZ 400 | 400 | 0.28-0.32 | 1.5 | 40-55 | 160-220 |
