SPZFm-10 Sluice Gate Valve

SPF gate valve is wide open and wide closed, suitable for installation in the cyclone to mine, tailings pipeline or double-circuit pipeline need to open and close the case of switch, suitable for the medium of slurry, ash and slag slurry, acid, alkali and other corrosive media.

Shangpin SPF gate valve products are generally manual, according to user requirements can be made into pneumatic, both on-site operation, can also be very convenient remote control. Structure length and flange size, according to national standards.

0086-631-5711169

Detail

Product introduction

Shangpin SPF gate valve products are generally manual, according to user requirements can be made into pneumatic, both on-site operation, can also be very convenient remote control. Structure length and flange size, according to national standards.

Technical characteristics

Nominal diameter DN	L	D1	n-M	n-φd	H	D
50	40	125	4-M16	2-φ18	680	160
65	40	145	4-M16	2-φ18	735	160
80	50	160	4-M16	4-φ18	790	180
100	50	180	4-M16	4-φ18	885	220
150	60	240	4-M20	4-φ22	1060	280
200	60	295	4-M20	4-φ22	1200	280
250	70	350	8-M20	4-φ22	1420	280
300	70	400	8-M20	4-φ22	1580	360
350	80	460	12-M20	4-φ22	1700	400
400	80	515	12-M20	4-φ22	1820	400
450	90	565	16-M24	6-φ28	1950	500
500	90	620	16-M24	6-φ28	2080	500
