SPGFm-10 Rubber Hose Valve
The rubber hose valve is mainly used in water treatment, mineral processing and other industries. The rubber hose is made of imported natural rubber with high elasticity, high wear resistance and fatigue resistance. The suitable medium is slurry, ash and slag, and corrosive media such as acid and alkali.
Detail
Product introduction
The rubber hose valve is mainly used in water treatment, mineral processing and other industries. The rubber hose is made of imported natural rubber with high elasticity, high wear resistance and fatigue resistance. The suitable medium is slurry, ash and slag, and corrosive media such as acid and alkali.
Technical characteristics
Nominal diameter DN | L | D1 | n-M | n-φd | H |
50 | 195 | 125 | 4-φ18 | 317 | |
65 | 220 | 145 | 4-φ18 | 345 | |
80 | 350 | 160 | 4-M16 | 4-φ18 | 363 |
100 | 376 | 180 | 4-M16 | 4-φ18 | 408 |
125 | 445 | 210 | 4-M16 | 4-φ18 | 448 |
150 | 495 | 240 | 4-M20 | 4-φ22 | 484 |
200 | 650 | 295 | 4-M20 | 4-φ22 | 578 |
